Description
Product Description:
The label uses the energy of radio waves to light the LED light, so no batteries are needed. It can greatly improve work efficiency and save costs. The LED label can be widely used in warehouse management, library management, archives management, logistics management, jewelry and power industry.
Product Parameters:
| Item | Description | |
| Product | UHF RFID With LED Light Label Mi9503-KX2005X-BL | |
| Chip Type | KX2005X-BL | |
| EPC Memory | 240Bits | |
| User Memory | 1312Bits | |
| TID Memory | 96Bits | |
| Frequency | 860～960MHz | |
| Operating Mode | Passive | |
| Protocol | Class 1 Gen 2 ( V1.2.0)、ISO/IEC 180006C | |
| ESD Voltage Immunity | 2KV Max. 2000V | |
| IC Life | 100,000 Programming cycles, 10 years data retention | |
| Operating Temperature/Humidity | [-25°C to +50°C]/ 20% to 80% | |
| Storage Temperature/Humidity | From the date of manufacture, 1 year at 23±5℃ / 50%±10%RH), un-seal the vacuum bag and avoid direct sunlight exposure. | |
| ANTENNA SIZE(mm) | 95*3mm | |
| Available Dimensions(mm) | 110*12mm | |
| or Customized | ||
| Application | Logistics, clothing, Unmanned retail, medical supplies management and other assets tracking | |
| Disclaimer | Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation. | |
