Description
Product Description:
The RFID windshield label serves for the automatic, contactless identification of vehicles (Automatic Vehicle Identification, AVI) The label is attached to the inside of the windshield. The develompent of the RFID windshield label has been focused on a very high read range due to the special antenna behind the glass and a passive function without a battery. The privacy protection is realised via an untraceale command. The label material is a combination of double PET layers. Extra security kiss cuts improve security against removal and re-use.
Product Parameters:
| Item | Description | |
| Product | UHF RFID Windshield Label 9954-Higgs9 | |
| Chip Type | Alien/Higgs9 | |
| EPC Memory | 96~496Bits | |
| User Memory | Up to 688Bits | |
| TID Memory | 48Bits | |
| Frequency | 860～960MHz | |
| Operating Mode | Passive | |
| Protocol | ISO/IEC 18000-6C EPC Class1 Gen2 | |
| ESD Voltage Immunity | 2KV Max. 2000V | |
| IC Life | 100,000 Programming cycles, 10 years data retention | |
| Operating Temperature/Humidity | [-25°C to +50°C]/ 20% to 80% | |
| Storage Temperature/Humidity | From the date of manufacture, 1 year at 23±5℃ / 50%±10%RH), un-seal the vacuum bag and avoid direct sunlight exposure. | |
| ANTENNA SIZE(mm) | 93*19mm | |
| Available Dimensions(mm) | 100*38mm | |
| or Customized | ||
| Application | Logistics, clothing, Unmanned retail, medical supplies management and other assets tracking | |
| Disclaimer | Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation. | |
