Description
Product Description:
The E61-Monza R6-P is a highly efficient UHF RFID tag tailored for packaging applications. The tag uses the Monza R6-P chip and complies with the ISO 18000-6C protocol, providing excellent read range and data accuracy. Its rugged and compact design makes it suitable for a variety of packaging materials, ensuring reliable tracking and inventory management throughout the supply chain. The tag is designed to withstand the challenges of diverse packaging environments, improve operational efficiency and reduce errors, and can accurately and efficiently monitor packaged goods, improving visibility and management of links such as overall logistics.
Product Parameters:
| Item | Description | |
| Product | UHF RFID Packaging label E61-Monza R6-P | |
| Chip Type | Impinj/Monza R6-P | |
| EPC Memory | 128Bits | |
| User Memory | 32Bits | |
| TID Memory | 48Bits | |
| Frequency | 860～960MHz | |
| Operating Mode | Passive | |
| Protocol | ISO 18000-63/Gen2v2 | |
| ESD Voltage Immunity | 2KV Max. 2000V | |
| IC Life | 100,000 Programming cycles, 10 years data retention | |
| Operating Temperature/Humidity | [-25°C to +50°C]/ 20% to 80% | |
| Storage Temperature/Humidity | From the date of manufacture, 1 year at 23±5℃ / 50%±10%RH), un-seal the vacuum bag and avoid direct sunlight exposure. | |
| ANTENNA SIZE(mm) | 95*8mm | |
| Available Dimensions(mm) | 98*15mm | |
| or Customized | ||
| Application | Logistics, clothing, Unmanned retail, medical supplies management and other assets tracking | |
| Disclaimer | Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation. | |
