Description
Product Description:
The HF RFID Medical Mini Label Mi1808 is a compact, high-frequency RFID tag designed for specialized and efficient tracking applications in medical environments and power asset management.Its adhesive backing allows for easy application to a variety of surfaces, making it suitable for tracking medical supplies, equipment, and power assets. The Mi1808 is built to withstand diverse environments, ensuring durability and long-term functionality. This mini label is an ideal solution for businesses and organizations seeking to enhance their tracking capabilities and operational efficiency.
Product Parameters:
| Item | Description |
| Product | HF RFID Medical Mini Labels Mi1808 |
| Chip Type | HF chip all available |
| User Memory | 144 bytes |
| Frequency | 13.56MΗz |
| Operating Mode | Passive |
| Protocol | ISO/IEC 14443 A |
| ESD Voltage Immunity | 2KV |
| IC Life | 100,000 Programming cycles, 10 years data retention |
| Operating Temperature/Humidity | [-25°C to +50°C]/ 20% to 80% |
| Storage Temperature/Humidity | From the date of manufacture, 1 year at 23±5℃ / 50%±10%RH), un-seal the vacuum bag and avoid direct sunlight exposure. |
| ANTENNA SIZE(mm) | 18*08mm |
| Available Dimensions(mm) | 21*11mm |
| or Customized | |
| Application | Medical, power asset management, etc. |
| Disclaimer | Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation. |
